| Electrical | |
|---|---|
| average input power max (W) | 350 |
| connectors | N-Female |
| frequency range (MHz) | 148 to 174 |
| impedance (Ω) | 50 |
| isolation (min) (dB) | 80 |
| Mechanical | |
|---|---|
| actual shipping weight (lbs) | 70 |
| cavity height | 24 |
| cavity height (in) | 24 |
| coupling loops material | copper |
| depth (in) | 14.9 |
| end plates material | aluminum |
| finish | chemical conversion |
| inner conductor material | silver plated brass |
| length height (in) | 32.5 |
| mounting configurations | 19 inch rack |
| outer conductor material | aluminum |
| shipping dimensions (in) | 22x22x43 |
| tuning rod material | invar |
| Width (in) | 19 |
| Environmental | |
|---|---|
| temperature range (°C) | -40 to 60 |
Q202GR-2-Spec-Sheet.pdf
