Electrical | |
---|---|
cavity electrical length | 04-Jan |
frequency range (MHz) | 406 to 440 |
impedance (Ω) | 50 |
input connectors | N-Female |
insertion loss typ tx to ant | 3.3 |
isolation antenna to tx | 25 |
isolation tx to tx | 35 |
number of channels | 4 |
output connectors | N-Female |
output vswr | 2:01 |
Mechanical | |
---|---|
actual shipping weight (lbs) | 53 |
depth (in) | 14.8 |
length height (in) | 15.3 |
mounting configurations | 19 inch rack |
shipping dimensions (in) | 20x16x21 |
Width (in) | 19 |
Environmental | |
---|---|
temperature range (°C) | -30 to 60 |
