CT6453F

Combiner, 10" cavities, 3/4 wave, High 'Q', 6 CH, 406-512 MHz

Regular price $0.00
/

Only 0 items in stock!
• Minimum Tx-Tx separation of 0.075 MHz
• Low loss dual stage isolators
• Equipment is mounted in two Sinclair Open Frame Racks which are included
Electrical
cavity electrical length 04-Mar
frequency range (MHz) 406 to 512
impedance (Ω) 50
input connectors N-Female
isolation antenna to tx 60
isolation antenna to tx (dB) 60
isolation tx to tx 70
isolation tx to tx (dB) 70
number of channels 6
output connectors N-Female
output vswr 2:01
Mechanical
coupling loops material copper
depth (in) 21
inner conductor material silver plated brass
length height (in) 76
mounting configurations Sinclair Open Frame Rack
outer conductor material aluminum
shipping dimensions (in) 22x22x43
tuning rod material invar
Width (in) 21
Environmental
temperature range (°C) -30 to 60
