Duplexer, base station, Q-Circuit, 4 cavity, rack mount, 132-148 MHz
Duplexer, base station, Q-Circuit, 4 cavity, rack mount, 132-148 MHz

Q202GR-1

Duplexer, base station, Q-Circuit, 4 cavity, rack mount, 132-148 MHz

Regular price $0.00
/

Only 0 items in stock!
• Four cavity configuration provides very high attention at extremely close frequency separation
• Quasi-bandpass response results in suppression of spurious and sideband transmitter noise
• Easy rack mount configuration
Electrical
average input power max (W) 350
connectors N-Female
frequency range (MHz) 132 to 148
impedance (Ω) 50
isolation (min) (dB) 80
Mechanical
actual shipping weight (lbs) 70
cavity height 26
cavity height (in) 26
coupling loops material copper
depth (in) 14.9
end plates material aluminum
inner conductor material silver plated brass
length height (in) 35
mounting configurations 19 inch rack
outer conductor material aluminum
shipping dimensions (in) 22x22x43
tuning rod material invar
Width (in) 19
Environmental
temperature range (°C) -40 to 60
